X / Y / Z axes travel : 610 / 450 / 450 mm
Table size ( X x Y ) : 700 x 450 mm
Table load capacity : 450 kg
Spindle speed : Belt 8,000 / 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 32 / 32 / 24 m/min.
X / Y / Z axes travel : 650 / 510 / 510 mm
Table size ( X x Y ) : 750 x 510 mm
Table load capacity : 500 kg
Spindle speed : Belt-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 32 m/min.
X / Y / Z axes travel : 800 / 510 / 510 mm
Table size ( X x Y ) : 860 x 510 mm
Table load capacity : 500 kg
Spindle speed : Belt-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 32 m/min.
X / Y / Z axes travel : 760 / 510 / 510 mm
Table size ( X x Y ) : 860 x 510 mm
Table load capacity : 500 kg
Spindle speed : Belt 8,000 / 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 32 m/min.
X / Y / Z axes travel : 860 / 650 / 610 mm
Table size ( X x Y ) : 1,000 x 650 mm
Table load capacity : 700 kg
Spindle speed : Belt-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 36 m/min.
X / Y / Z axes travel : 1,020 / 550 / 635 mm
Table size ( X x Y ) : 1,200 x 550 mm
Table load capacity : 700 kg
Spindle speed : Belt-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 36 / 36 / 24 m/min.
X / Y / Z axes travel : 1,060 / 650 / 610 mm
Table size ( X x Y ) : 1,200 x 650 mm
Table load capacity : 700 kg
Spindle speed : Belt-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 36 m/min.
X / Y / Z axes travel : 1,250 / 650 / 610 mm
Table size ( X x Y ) : 1,350 x 650 mm
Table load capacity : 1,000 kg
Spindle speed : Belt-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 36 m/min.
X / Y / Z axes travel : 1,400 / 620 / 620 mm
Table size ( X x Y ) : 1,500 x 620 mm
Table load capacity : 1,000 kg
Spindle speed : Belt 8,000 / 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 36 m/min.
X / Y / Z axes travel : 1,400 / 650 / 610 mm
Table size ( X x Y ) : 1,500 x 650 mm
Table load capacity : 1,000 kg
Spindle speed : Belt-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
X / Y / Z axes rapid feed rate : 48 / 48 / 36 m/min.
X / Y / Z axes travel : 1,400 / 800 / 800 mm
Table size ( X x Y ) : 1,500 x 800 mm
Table load capacity : 1,200 kg
Spindle speed : Direct-drive 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min.
X / Y / Z axes travel : 1,600 / 800 / 800 mm
Table size ( X x Y ) : 1,700 x 800 mm
Table load capacity : 1,500 kg
Spindle speed : Direct-drive 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min.
X / Y / Z axes travel : 1,800 / 800 / 800 mm
Table size ( X x Y ) : 1,900 x 800 mm
Table load capacity : 1,800 kg
Spindle speed : Direct-drive 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min.
X / Y / Z axes travel : 850 / 650 / 610 mm
Table size ( X x Y ) : 1,050 x 650 mm
Table load capacity : 850 kg
Spindle speed : 8,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
Spindle taper : BT40 ( BT50 Opt. )
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min
X / Y / Z axes travel : 1,020 / 650 / 610 mm
Table size ( X x Y ) : 1,120 x 650 mm
Table load capacity : 1,000 kg
Spindle speed : 8,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
Spindle taper : BT40 ( BT50 Opt. )
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min
X / Y / Z axes travel : 1,200 / 650 / 610 mm
Table size ( X x Y ) : 1,300 x 650 mm
Table load capacity : 1,200 kg
Spindle speed : 8,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
Spindle taper : BT40 ( BT50 Opt. )
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min
X / Y / Z axes travel : 1,400 / 650 / 610 mm
Table size ( X x Y ) : 1,500 x 650 mm
Table load capacity : 1,400 kg
Spindle speed : 8,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
Spindle taper : BT40 ( BT50 Opt. )
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min
X / Y / Z axes travel : 1,500 / 740 / 610 mm
Table size ( X x Y ) : 1,600 x 700 mm
Table load capacity : 1,450 kg
Spindle speed : 8,000 rpm
Spindle motor ( cont. / 30 min. ) : 7.5 / 11 kW
Spindle taper : BT40 ( BT50 Opt. )
X / Y / Z axes rapid feed rate : 30 / 30 / 24 m/min
X / Y / Z axes travel : 1,400 / 800 / 700 mm
Table size ( X x Y ) : 1,500 x 800 mm
Table load capacity : 1,800 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
Spindle taper : BT50 ( BT40 Opt. )
X / Y / Z axes rapid feed rate : 20 / 20 / 18 m/min.
X / Y / Z axes travel : 1,600 / 800 / 800 mm
Table size ( X x Y ) : 1,700 x 800 mm
Table load capacity : 2,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
Spindle taper : BT50 ( BT40 Opt. )
X / Y / Z axes rapid feed rate : 20 / 20 / 18 m/min.
X / Y / Z axes travel : 1,800 / 800 / 800 mm
Table size ( X x Y ) : 2,000 x 800 mm
Table load capacity : 2,200 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
Spindle taper : BT50 ( BT40 Opt. )
X / Y / Z axes rapid feed rate : 20 / 20 / 18 m/min.
X / Y / Z axes travel : 2,100 / 1,000 / 1,000 mm
Table size ( X x Y ) : 2,300 x 1,000 mm
Table load capacity : 3,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 15 / 18.5 kW
Spindle taper : BT50
X / Y / Z axes rapid feed rate : 15 / 15 / 12 m/min.
X / Y / Z axes travel : 2,500 / 1,000 / 1,000 mm
Table size ( X x Y ) : 2,700 x 1,000 mm
Table load capacity : 4,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 15 / 18.5 kW
Spindle taper : BT50
X / Y / Z axes rapid feed rate : 15 / 15 / 12 m/min.
X / Y / Z axes travel : 1,600 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 1,600 x 1,100 mm
Table load capacity : 3,000 kg
Spindle speed : Gear spindle 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes travel : 1,600 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 1,600 x 1,100 mm
Table load capacity : 3,000 kg
Spindle speed : 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 2,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 2,000 x 1,100 mm
Table load capacity : 3,500 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes travel : 2,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 2,000 x 1,100 mm
Table load capacity : 3,500 kg
Spindle speed : 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 2,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 2,000 x 1,100 mm
Table load capacity : 4,500 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 2,100 / 1,600 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 2,310 x 1,500 mm
Table load capacity : 8,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 2,500 / 1,600 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 2,310 x 1,500 mm
Table load capacity : 8,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 2,500 / 1,600 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 2,310 x 1,500 mm
Table load capacity : 8,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 2,500 / 1,900 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 2,310 x 1,500 mm
Table load capacity : 8,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 2,500 / 1,900 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 2,310 x 1,500 mm
Table load capacity : 8,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 3,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 3,000 x 1,100 mm
Table load capacity : 4,500 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes travel : 3,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 3,000 x 1,100 mm
Table load capacity : 4,500 kg
Spindle speed : 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 3,000 x 1,100 mm
Table load capacity : 5,500 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,060 / 1,600 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 3,260 x 1,500 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 1,600 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 3,260 x 1,500 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 3,000 / 1,600 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 3,260 x 1,500 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 3,000 / 1,900 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 3,260 x 1,500 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 3,000 / 1,900 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 3,260 x 1,500 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 3,000 / 2,100 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 3,020 x 2,010 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 2,100 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 3,020 x 2,010 mm
Table load capacity : 10,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 2,500 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 3,020 x 2,400 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 2,500 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 3,020 x 2,400 mm
Table load capacity : 12,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 3,020 x 2,010 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 3,020 x 2,010 mm
Table load capacity : 10,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 3,020 x 2,400 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 3,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 3,020 x 2,400 mm
Table load capacity : 12,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 4,000 x 1,100 mm
Table load capacity : 6,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes travel : 4,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 4,000 x 1,100 mm
Table load capacity : 6,000 kg
Spindle speed : 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 1,600 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 4,200 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 1,600 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 4,200 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 4,000 / 1,600 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 4,200 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 4,000 / 1,900 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 4,200 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 4,000 / 1,900 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 4,200 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 40 Opt. )
X / Y / Z axes travel : 4,000 / 2,100 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 4,020 x 2,010 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 2,100 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 4,020 x 2,010 mm
Table load capacity : 12,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 4,020 x 2,010 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 2,500 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 2,500 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 2,500 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 2,500 / 1,200 ( 1,400 ) mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 4,020 x 2,010 mm
Table load capacity : 12,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 3,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T
X / Y / Z axes travel : 4,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 3,200 / 1,200 ( 1,400 ) mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 3,300 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 3,300 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 4,000 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 4,100 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 4,100 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 4,800 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 4,000 / 4,800 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 4,020 x 3,000 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 5,000 x 1,100 mm
Table load capacity : 8,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 11 / 15 kW
X / Y / Z axes travel : 5,000 / 1,200 / 760 mm
Dist. between columns : 1,300 mm
Table size ( X x Y ) : 5,000 x 1,100 mm
Table load capacity : 8,000 kg
Spindle speed : 10,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 1,600 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 5,000 x 1,500 mm
Table load capacity : 14,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 ( 40 Opt. )
X / Y / Z axes travel : 5,000 / 1,600 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 5,000 x 1,500 mm
Table load capacity : 14,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 ( 40 Opt. )
X / Y / Z axes travel : 5,000 / 1,900 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 5,000 x 1,500 mm
Table load capacity : 14,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 ( 40 Opt. )
X / Y / Z axes travel : 5,000 / 1,900 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 5,000 x 1,500 mm
Table load capacity : 14,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 ( 40 Opt. )
X / Y / Z axes travel : 5,000 / 2,100 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 5,020 x 2,010 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 2,100 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 5,020 x 2,010 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 5,020 x 2,010 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 2,500 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 2,500 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 2,500 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 2,500 / 1,200 ( 1,400 ) mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 5,020 x 2,010 mm
Table load capacity : 15,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 3,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T
X / Y / Z axes travel : 5,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 3,200 / 1,200 ( 1,400 ) mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 3,300 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm)
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 3,300 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 4,000 / 1,000 mm
Dist. between columns : 4,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 5,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 4,000 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 4,100 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 4,100 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 4,800 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 5,000 / 4,800 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 5,020 x 3,000 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 2,100 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 6,020 x 2,010 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 2,100 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 6,020 x 2,010 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 6,020 x 2,010 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 2,500 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 2,500 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 2,500 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 2,500 / 1,200 ( 1,400 ) mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 6,020 x 2,010 mm
Table load capacity : 18,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 3,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T
X / Y / Z axes travel : 6,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 3,200 / 1,200 ( 1,400 ) mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 3,300 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 3,300 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 4,000 / 1,000 mm
Dist. between columns : 4,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 6,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 4,000 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 4,100 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 4,100 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 4,800 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 4,800 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 6,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 6,000 / 5,000 / 1,000 mm
Dist. between columns : 5,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 7,000 / 3,300 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 7,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 7,000 / 3,300 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 7,000 / 3,300 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 7,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 7,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 / 90 / 120 Opt. )
X / Y / Z axes travel : 7,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 7,000 / 4,000 / 1,200 ( 1,400 ) mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 7,000 / 4,100 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 7,000 / 4,100 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 7,000 / 4,800 / 1,000 mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 7,000 / 4,800 / 1,200 ( 1,400 ) mm
Dist. between columns : 4,300 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 4,000 rpm
Spindle motor ( Cont. /30min.) : 22 / 26 kW( 30 / 37 Opt.)
Tool magazine capacity : 32 T ( 40 / 60 / 90 / 120 Opt.)
X / Y / Z axes travel : 8,000 / 3,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T
X / Y / Z axes travel : 8,000 / 4,000 / 1,000 mm
Dist. between columns : 4,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 8,000 / 5,000 / 1,000 mm
Dist. between columns : 5,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 10,000 / 3,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T
X / Y / Z axes travel : 10,000 / 4,000 / 1,000 mm
Dist. between columns : 4,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 10,000 / 5,000 / 1,000 mm
Dist. between columns : 5,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 10,000 / 7,000 / 1,000 mm
Dist. between columns : 7,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 14,000 / 5,000 / 1,000 mm
Dist. between columns : 5,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 20,000 / 7,000 / 1,000 mm
Dist. between columns : 7,500 mm
Table load capacity : 2,500 kg/m²
Spindle speed : 4,000 rpm ( 5,000 / 6,000 / 8,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 32 T ( 60 Opt. )
X / Y / Z axes travel : 700 / 500 / 350 mm
Table size ( X x Y ) : 770 x 500 mm
Table load capacity : 600 kg
Spindle speed : Build-in 21,000 rpm
Spindle motor ( cont. / 30 min. ) : 18 / 24 kW
Cutting feed rate : 24 m/min.
X / Y / Z axes travel : 800 / 700 / 420 mm
Table size ( X x Y ) : 850 x 700 mm
Table load capacity : 800 kg
Spindle speed : Build-in 15,000 rpm
Spindle motor ( cont. / 15 min. ) : 15 / 18.5 kW
Cutting feed rate : 24 m/min.
X / Y / Z axes travel : 1,000 / 600 / 500 mm
Table size ( X x Y ) : 1,160 x 600 mm
Table load capacity : 1,000 kg
Spindle speed : Direct-driven 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 15 / 18.5 kW
Cutting feed rate : 20 m/min.
X / Y / Z axes travel : 1,000 / 1,000 / 500 mm
Table size ( X x Y ) : 1,100 x 1,000 mm
Table load capacity : 2,000 kg
Spindle speed : Direct-driven 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 15 / 18.5 kW
Cutting feed rate : 20 m/min.
Dist. from spindle nose to table top : 160 ~ 920 mm
Dist. between columns : 1,300 mm
Table load capacity : 3,500 kg
Spindle motor ( cont. / 30 min. ) : 18.5 / 22 kW
Spindle speed : 15,000 rpm
Spindle taper : BT40
Dist. from spindle nose to table top : 160 ~ 920 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 2,310 x 1,500 mm
Table load capacity : 8,000 kg
Spindle motor ( cont. / 30 min. ) : 18.5 / 22 kW
Spindle speed : 15,000 rpm
Dist. from spindle nose to table top : 160 ~ 920 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 3,260 x 1,500 mm
Table load capacity : 10,000 mm
Spindle motor ( cont. / 30 min. ) : 18.5 / 22 kW
Spindle speed : 15,000 rpm
X / Y / Z axes travel : 3,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 3,020 x 2,010 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 3,020 x 2,010 mm
Table load capacity : 10,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 3,020 x 2,400 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 3,020 x 2,400 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,060 / 2,500 / 1,000 mm
Dist. between columns : 1,800 mm
Table size ( X x Y ) : 3,260 x 1,500 mm
Table load capacity : 10,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 1,900 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 4,200 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed ( Vertical ) : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle speed ( Horizontal) : 2,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 1,900 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 4,200 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed ( Vertical ) : 4,000 rpm
Spindle speed ( Horizontal) : 2,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 4,020 x 2,010 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 2,500 / 1,000 mm
Dist. between columns : 1,800 mm
Table size ( X x Y ) : 4,020 x 1,500 mm
Table load capacity : 12,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 4,020 x 2,010 mm
Table load capacity : 12,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 3,200 / 1,000 mm
Dist. between columns : 2,500 mm
Table size ( X x Y ) : 4,020 x 2,010 mm
Table load capacity : 12,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 3,200 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 3,900 / 1,000 mm
Dist. between columns : 3,200 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 4,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 2,400 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 4,000 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 4,020 x 3,010 mm
Table load capacity : 15,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 1,900 / 760 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 5,000 x 1,500 mm
Table load capacity : 14,000 kg
Spindle speed ( Vertical ) : 6,000 rpm ( 8,000 / 10,000 Opt. )
Spindle speed ( Horizontal) : 2,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 1,900 / 1,000 mm
Dist. between columns : 1,700 mm
Table size ( X x Y ) : 5,000 x 1,500 mm
Table load capacity : 14,000 kg
Spindle speed ( Vertical ) : 4,000 rpm
Spindle speed ( Horizontal) : 2,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 5,020 x 2,010 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 5,020 x 2,010 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 3,200 / 1,000 mm
Dist. between columns : 2,500 mm
Table size ( X x Y ) : 5,020 x 2,010 mm
Table load capacity : 15,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 3,200 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 3,200 / 1,000 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 3,900 / 1,000 mm
Dist. between columns : 3,200 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 5,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 2,400 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 5,000 / 4,000 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 5,020 x 3,010 mm
Table load capacity : 18,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 2,800 / 760 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 6,020 x 2,010 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 2,800 / 1,000 mm
Dist. between columns : 2,300 mm
Table size ( X x Y ) : 6,020 x 2,010 mm
Table load capacity : 18,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 3,200 / 1,000 mm
Dist. between columns : 2,500 mm
Table size ( X x Y ) : 6,020 x 2,010 mm
Table load capacity : 17,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 3,200 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 3,200 / 760 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 3,900 / 1,000 mm
Dist. between columns : 3,200 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 6,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 4,000 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 6,020 x 3,010 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 6,000 / 4,500 / 1,000 mm
Dist. between columns : 3,300 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 7,000 / 3,200 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 7,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 7,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 7,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 7,000 / 4,000 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,010 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 7,000 / 4,500 / 1,000 mm
Dist. between columns : 3,300 mm
Table size ( X x Y ) : 6,020 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 2,400 rpm ( stepless )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T ( 90 / 120 Opt. )
X / Y / Z axes travel : 8,000 / 3,200 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 2,700 mm
Table size ( X x Y ) : 8,040 x 2,400 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 8,000 / 4,000 / 1,000 mm
W-axis travel : 1,250 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 8,040 x 3,010 mm
Table load capacity : 20,000 kg
Spindle speed ( V / H ) : 4,000 / 3,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 8,000 / 4,000 / 760 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 8,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 7,000 / 4,000 / 1,000 mm
Dist. between columns : 3,500 mm
Table size ( X x Y ) : 7,020 x 3,000 mm
Table load capacity : 20,000 kg
Spindle speed : 6,000 rpm ( 8,000 / 10,000 / 12,000 Opt. )
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 8,000 / 4,400 / 1,400 mm
Dist. between columns : 3,700 mm
Table size ( X x Y ) : 8,000 x 2,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 8,000 / 5,400 / 1,400 mm
Dist. between columns : 4,700 mm
Table size ( X x Y ) : 8,000 x 3,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 8,000 / 6,400 / 1,400 mm
Dist. between columns : 5,700 mm
Table size ( X x Y ) : 8,000 x 4,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 10,000 / 4,400 / 1,400 mm
Dist. between columns : 3,700 mm
Table size ( X x Y ) : 10,000 x 2,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 10,000 / 5,400 / 1,400 mm
Dist. between columns : 4,700 mm
Table size ( X x Y ) : 10,000 x 3,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 10,000 / 6,400 / 1,400 mm
Dist. between columns : 5,700 mm
Table size ( X x Y ) : 10,000 x 4,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 12,000 / 4,400 / 1,400 mm
Dist. between columns : 3,700 mm
Table size ( X x Y ) : 12,000 x 2,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 12,000 / 5,400 / 1,400 mm
Dist. between columns : 4,700 mm
Table size ( X x Y ) : 12,000 x 3,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 12,000 / 6,400 / 1,400 mm
Dist. between columns : 5,700 mm
Table size ( X x Y ) : 12,000 x 4,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 14,000 / 4,400 / 1,400 mm
Dist. between columns : 3,700 mm
Table size ( X x Y ) : 14,000 x 2,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 14,000 / 5,400 / 1,400 mm
Dist. between columns : 4,700 mm
Table size ( X x Y ) : 14,000 x 3,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 14,000 / 6,400 / 1,400 mm
Dist. between columns : 5,700 mm
Table size ( X x Y ) : 14,000 x 4,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 16,000 / 4,400 / 1,400 mm
Dist. between columns : 3,700 mm
Table size ( X x Y ) : 16,000 x 2,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 16,000 / 5,400 / 1,400 mm
Dist. between columns : 4,700 mm
Table size ( X x Y ) : 16,000 x 3,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 16,000 / 6,400 / 1,400 mm
Dist. between columns : 5,700 mm
Table size ( X x Y ) : 16,000 x 4,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 18,000 / 4,400 / 1,400 mm
Dist. between columns : 3,700 mm
Table size ( X x Y ) : 18,000 x 2,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 18,000 / 5,400 / 1,400 mm
Dist. between columns : 4,700 mm
Table size ( X x Y ) : 18,000 x 3,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 18,000 / 6,400 / 1,400 mm
Dist. between columns : 5,700 mm
Table size ( X x Y ) : 18,000 x 4,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 20,000 / 4,400 / 1,400 mm
Dist. between columns : 3,700 mm
Table size ( X x Y ) : 20,000 x 2,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 20,000 / 5,400 / 1,400 mm
Dist. between columns : 4,700 mm
Table size ( X x Y ) : 20,000 x 3,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 20,000 / 6,400 / 1,400 mm
Dist. between columns : 5,700 mm
Table size ( X x Y ) : 20,000 x 4,800 mm
Spindle speed ( Vertical ) : 4,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 40 T ( 60 Opt. )
X / Y / Z axes travel : 780 / 670 / 650 mm
Table size ( X x Y ) / Number : 500 x 500 mm / 2
Table load capacity : 500 kg
Min. table index ( B-axis ) : 0.001° / 1°
Spindle speed : Direct drive 10,000 rpm / Gear 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T
X / Y / Z axes travel : 1,020 / 900 / 900 mm
Table size ( X x Y ) / Number : 630 x 630 mm / 2
Table load capacity : 1,200 kg
Min. table index ( B-axis ) : 0.001° / 1°
Spindle speed : Direct drive 10,000 rpm / Gear 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
Tool magazine capacity : 60 T
X / Y / Z axes travel : 2,000 / 1,800 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Quill with Ø 120 mm
Table load capacity : 15,000 kg
Spindle speed : 2,400 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 2,000 / 1,800 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Ram 480 x 470 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 2,000 / 2,400 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Quill with Ø 120 mm
Table load capacity : 15,000 kg
Spindle speed : 2,400 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 2,000 / 2,400 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : RAM 480 x 470 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,000 / 1,800 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Quill with Ø 120 mm
Table load capacity : 15,000 kg
Spindle speed : 2,400 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 1,800 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Ram 480 x 470 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,000 / 2,400 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Quill with Ø 120 mm
Table load capacity : 15,000 kg
Spindle speed : 2,400 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 3,000 / 2,400 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : RAM 480 x 470 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 1,800 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Quill with Ø 120 mm
Table load capacity : 15,000 kg
Spindle speed : 2,400 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 1,800 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Ram 480 x 470 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 2,400 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : Quill with Ø 120 mm
Table load capacity : 15,000 kg
Spindle speed : 2,400 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 4,000 / 2,400 / 1,300 mm
W-axis travel : 600 mm
Table size ( X x Y ) : 1,600 x 1,800 mm
Boring spindle size : RAM 480 x 470 mm
Table load capacity : 15,000 kg
Spindle speed : 6,000 rpm
Spindle motor ( cont. / 30 min. ) : 22 / 26 kW
X / Y / Z axes travel : 560 / 510 / 460 mm
A / C axes travel : 200˚ ( 100˚ ~ -100˚ ) / 360°
Table size ( X x Y ) : Ø 210 mm
Table load capacity : 0° : 75 ; 0°~ 90° : 50 kg
Spindle speed : 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 5.5 / 7.9 kW
X / Y / Z axes rapid feed rate : 32 / 32 / 24 m/min.
X / Y / Z axes travel : 960 / 600 / 480 mm
A / C axes travel : 162˚ ( -42˚ ~ +120˚ ) / 360°
Table size ( X x Y ) : 560 x 365 mm ( Ø 350 mm )
Table load capacity : 0° : 200 ; 45°~ 90° : 150 kg
Spindle speed : 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 10 / 14 kW
X / Y / Z axes rapid feed rate : 32 / 32 / 24 m/min.
X / Y / Z axes travel : 500 / 400 / 400 mm
B / C axes travel : +30° ~ -120° / 360°
Table size ( X x Y ) : Ø 400 mm
Table load capacity : 200 kg
Spindle speed : 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 15 / 18.5 kW
X / Y / Z axes rapid feed rate : 30 m/min.
X / Y / Z axes travel : 500 / 450 / 450 mm
B / C axes travel : -180° ~ +160° / 360°
Table size ( X x Y ) : Ø 450 ; 400 x 400 mm
Table load capacity : 300 kg
Spindle speed : 16,000 rpm
Spindle motor ( cont. / 30 min. ) : 25 / 29 kW
X / Y / Z axes rapid feed rate : 48 m/min.
X / Y / Z axes travel : 635 / 535 / 460 mm
B / C axes rotary range : -50˚ ~ +110˚ / 360°
Table diameter : Ø 650 mm
Table load capacity : 0° ~ 45° 300 kg / 45° ~ 90° 200 kg
Spindle speed : Direct drive 12,000 / Built-in 16,000 rpm
Spindle motor ( cont. / min ) : 11 / 15 kW
X / Y / Z axes rapid feed rate : 36 m/min.
X / Y / Z axes travel : 800 / 900 / 660 mm
A / C axes travel : -120° ~ +30° / 360°
Table size ( X x Y ) : Ø 850 mm
Table load capacity : 0° : 1,000 kg / 90° : 700 kg
Spindle speed : Built-in spindle 16,000 rpm
Spindle motor ( cont. / 30 min. ) : 26 kW
X / Y / Z axes rapid feed rate : 48 m/min.
X-axis travel : 2,500 ~ 6,000 mm
Y-axis travel : 2,620 / 3,200 mm
Z-axis travel : 1,000 mm ( 1,200 mm Opt. )
B / C axes travel ( TCH-20F ) : ±100° / ±250°
B / C axes travel ( TCH-30F ) : ±110° / ±250°
Table load capacity : 8,000 ~ 20,000 kg
X/Y/Z axes rapid feed rate : 10~20 / 12~20 / 10~15 m/min.
X-axis travel : 1,600 / 3,200 mm
Y-axis travel : 2,000 mm
Z-axis travel : 1,000 mm
Dist. between columns ( with water eliminator ) : 3,500 (2,805)mm
Table load capacity : 3,000 kg/m²
X / Y axes rapid feed rate : 60 m/min.
Z-axis rapid feed rate : 50 m/min.
X-axis travel : 4,000 ~ 10,000 mm
Y-axis travel : 3,700 / 4,700 mm
Z-axis travel : 1,200 mm ( 1,400 mm Opt. )
B / C axes travel ( TCH-20F ) : ±100° / ±250°
B / C axes travel ( TCH-30F ) : ±110° / ±250°
Table load capacity : 2,500 kg/m²
X / Y / Z axes rapid feed rate : 20 / 12 ~ 15 / 10 m/min.
X-axis travel : 1,600 / 3,200 mm
Y-axis travel : 2,500 mm
Z-axis travel : 1,000 mm
Dist. between columns ( with water eliminator ) : 3,500 mm
Table load capacity : 2,500 kg/m²
X-axis rapid feed rate : 24 / 20 m/min.
Y / Z axes rapid feed rate : 24 m/min.
X / Y / Z axes travel : 6,000 / 3,000 / 1,500 mm
B / C axes travel : ±120° / ±270°
Spindle speed : 20,000 rpm
Spindle motor ( cont. / 30 min. ) : 15 / 18 kW
Spindle taper : HSK-A63
X / Y / Z axes rapid feed rate : 40 / 40 / 20 m/min.
Tool magazine capacity : 10 T
X / Y / Z axes travel : 510 / 400 / 350 mm
Table size ( X x Y ) : 610 x 400 mm
Table load capacity : 250 kg
Spindle speed : 12,000 rpm
Spindle motor ( cont. / 30 min. ) : 3.7 / 5.5 kW
X / Y / Z axes rapid feed rate : 50 / 50 / 45 m/min.
Table size : 800 x 460 mm
Table load capacity : 200 kg x 2
Rotation angle : ±180°
Positioning accuracy on Z-axis : 0.02 mm
Pallet changing time : 7 sec.
Table size : 800 x 460 mm
Table load capacity : 200 kg x 2
Rotation angle : ±180°
Positioning accuracy on Z-axis : 0.02 mm
Pallet changing time : 7 sec.
Table size : 1,250 x 1,150 mm
Table load capacity : 4,000 kg
B-axis rotray range : 360°
B-axis positioning accuracy : 0.001°
B-axis speed : 5 rpm
